🎧 We are reviewing the FX-AUDIO DAC-M1, the newest headphone amp/DAC from the brand.

The FX-AUDIO DAC-M1 is a solid state amp/DAC with impressive specs and their latest addition to the catalog, belonging to a brand new series: the “2.0 ERA UPGRADE” line.

FX-AUDIO is a brand that manufactures, exclusively, audio-related products; most specifically, DAC and amplifiers.

In the past we have reviewed their flagship tube amp which resulted in a phenomenal bang for buck option with very good performance overall.

The DAC-M1 is packed with advanced features and specs that are hard to reach by mainstream competitors at such a low asking price – we will test the unit and list in detail it’s features through out this FX-AUDIO DAC-M1 review.

You can buy the FX-AUDIO DAC-M1 in 3 colors:

FIND ALL: Headphones Scores Compared

MORE: Reviews – Headphones, Music Players, DAC, DAP, Amp, Cables

SEE ALSO: DAP/DAC Reviews


FX-AUDIO DAC-M1 Review

Tests & Scores


AF

Advanced Features

The FX-AUDIO DAC-M1 include advanced features such as:

  • USB DAC
  • Bluetooth 5.0
  • aptx/LDAC
  • PCM 768kHz / 32bit
  • DSD512 decoding
  • USB-C connection
  • Infrared remote control

MORE: In-Ear Headphones Weight Comparison

SEE ALSO: Earphones Size Comparison


A

Accessories & Packaging

The FX-AUDIO DAC-M1 comes inside a square packaging with good built and inner cutouts to protect the unit through shipping and handling.

The packaging has a mainly white design but the brand decided to include an odd “GOOD TIME” big writing on the top of the box instead of writing the brand name or the product’s model name.

The unit comes bundled with: an AC adapter, 1x AC cable, 1x USB-C cable, 1x IR remote control and 1x Bluetooth antenna.

gramophone-25660 4.25/5


D

Design

The FX-AUDIO DAC-M1 has a different form fact than the typical rectangular, thin and wide design of most DAC and amps on the market.

Instead, the brand opted for design that distributes it’s volume in a way less wide but taller ratio; while offering a remarkably tiny foot print.

In addition to this, FX-AUDIO has also decided to offer the unit in 2 rare colors that are never seen on desktop DAC/amps, a blue and a pink variant.

Overall, the DAC-M1 looks aesthetically pleasing with rounded edges and a clean design with a simple and non-cluttered front panel.

With a sort of metallic pearled finish the DAC has a popping but classy look that gets sculptured by light sources that reach it’s surface.

We usually do not concentrate on the power supply on our DAC/amps reviews, but the FX-AUDIO DAC-M1 has a remarkably tiny PSU and a crazy low power consumption of just 3.5W.

gramophone-25660 5/5


OC

Operation & Control

The FX-AUDIO DAC-M1 not only looks clean, design-wise, it is also extremely simple to use with 1 button and 1 single knob that fully control device – the knob is also a button by simply pressing it.

The knob offers infinite rotation (either clock and counterclockwise) with clicky steps that dial up/down the volume by 1 mark and result in a precise level of volume control with 100 steps (from 0 to 100)This knob is also a multi-function button for:

  • Press and hold: Access menu
  • Single press: Confirm option

FX-AUDIO DAC-M1 Infrared operation:

In addition to the physical knob/button, the FX-AUDIO DAC-M1 has an infrared sensor and comes with a bundled IR remote control that allows it to be fully operated wirelessly.

How to power the FX-AUDIO DAC-M1:

The DAC/Amp is powered by a PSU that provides 12V and 1A.

The device can be turned on and off either by pressing and holding the rounded button on the lower left angle of the front panel or through the remote control.

Despite not being labeled on the front panel, a single press of the aforementioned button will act as Mute On/Off.

gramophone-256605/5

MORE: Earphones Amplification Power Comparison

MORE: Best Basshead Earphones

SEE ALSO: Best Fun Sounding Earphones Chart


CB

Construction & Build

The FX-AUDIO DAC-M1 is very nicely build thanks to a full-aluminum-alloy anodized construction that ensures ruggedness and durability.

In spite of being a metal-built device, the unit is surprisingly light weighted.

In addition to this, the bottom of the unit is equipped with rubberized (almost silicone feeling alike) feet that do a fantastic job keeping the amp/DAC slippery-free.

On the other hand, both the button and knob present a bit of wobbling – mostly the On/Off button.

gramophone-256604.5/5

MORE: Best Headphones for Libraries Chart

SEE ALSO: Best Earphones for Bed

FX-AUDIO DAC-M1
FX-AUDIO DAC-M1

CM

Compatibility

The USB connection of the FX-AUDIO DAC-M1 enables the unit to be compatible with Windows, Mac and Linux while the COAX, optical, 1/4″ jack, RCA and Bluetooth connections make it a fully universal compatible device with smartphones, active speakers, headphones, amps, TV and media centers.

gramophone-256605/5


SC

Screen

The screen of the FX-AUDIO DAC-M1 might be the only Aquiles Talon of the whole offering by the brand.

The size of the screen is quite well for the unit’s dimension but the issue resides in the less-fancy font choice made by the brand and the non-optimized placement of the information provided on the display.

The top left corner of the screen informs the input mode, the center will show the sampling rate and format, the bottom left corner shows the output mode, the top right displays the volume and the bottom right informs the filter option used.

The screen brightness can be manually set in 4 different levels: 25%, 50%, 75%, 100%.

gramophone-256603/5




C

Connectivity

The FX-AUDIO DAC-M1 is equipped with 4 inputs and 2 outputs.

The front panel of the has a single 6.35mm headphone output connector while the back panel holds all the other I/O connections, such as:

  • USB-C input
  • Optical input
  • Coaxial input
  • RCA output
  • Wireless Bluetooth input

Connections Technical Specifications:

  • USB: up to 768kHz / 32bit
  • Optical/COAX: up to 192kHz / 32bit
  • Bluetooth 5.0: up to 96kHz / 24bit, LDAC /AAC /SBC /APTX /APTX-LL /APTX-HD

gramophone-256604.25/5

RELATED TO THIS: Active Noise Cancelling Headphones Reviews


SEE ALSO: Coupons – Discounts – Deals – Promo Codes – Sales Deals

S

Sound

The FX-AUDIO DAC-M1 hides beneath the tiny appearance some high-performance audiophile components to provide low noise, low distortion and excellent quality.

Some of the inner guts of the DAC-M1 include:

  • ESS9038Q2M DAC
  • XMOS XU208 USB
  • TPA6120A2 amp
  • OP1612 + 49720 op amp
  • CSR8675 Bluetooth chip

Moreover, the FX-AUDIO DAC-M1 offers a whopping maximum output power of 500mW @32ohm and worthwhile driving capability at 300 ohm (340mW @64ohm, 180mW @150 ohm, 96mW @ 300 ohm), vastly surpassing the power output of the TOPPING MX-3, FX-AUDIO TUBE-P1 or the FiiO K3.

Despite being a remarkably powerful amp/DAC for it’s price, the max output will not reach the insane power of other premium devices that we have reviewed such as the Mytek Brooklyn Bridge nor as the dedicated xDuoo TA-20 amp; yet, the FX-AUDIO DAC-M1 can easily drive any commercial in-ear or full-sized over-headphone without even breaking a sweat.

Through out our tests, the DAC-M1 had no difficulty driving headphones such as the beyerdynamic DT-990 PRO 250 ohm, beyerdynamic DT-7700 PRO 250 ohm, Sennheiser HD650, Sennheiser HD600, Sennheiser HD599. Testing all 5 models, showed sufficient output and volume margin to fulfill any listening sessions.

Furthermore, we proceeded to test the unit in search of nuances. The results showed no coloration nor distortion issues. Through out our measurements, the FX-AUDIO DAC-M1 presented a noticeably flat frequency response without any rolling-off, spikes, dips, abnormal peaks nor decay – in every single I/O modes (see our measurement curves latter ahead)

On top of that that, there were no perceivable channel imbalance issues.

Filter Modes

Advanced audiophiles will be happy to know that FX-AUDIO included 7 filter options with the DAC-M1 (mode displayed as FIR#):

  • FIR1: brick wall
  • FIR2: corrected minimum phase fast roll-off
  • FIR3: apodizing fast roll-off
  • FIR4: minimum phase low roll-off
  • FIR5: minimum phase fast roll-off
  • FIR6: linear phase low roll-off
  • FIR7: linear phase fast roll-off

Sound Technical Specifications

Some of main sound-related tech specs of the FX-AUDIO DAC-M1 are:

  • SNR: 118dB
  • THD+N: 0.00025%
  • Output: 500mW @32 Ω, 340mW @64 Ω, 180mW @150 Ω, 96mW @ 300 Ω

Tech-spec seekers might not get their thirst for curiosity quenched as the brand does not give a deep insight of the unit’s specification – besides THD+N, SNR and output-impedance.

gramophone-256605/5

RELATED: Best Earphones for Daily Commute

MORE: Most Comfortable In-Ear Headphones

MORE: Editor’s Picks Earphones Chart

MORE: Best Bang for the Buck Earphones


FW

FX-AUDIO DAC-M1 Firmware & Driver

The unit is automatically recognized and setup by Windows; which will download, install and configure the DAC as it corresponds.

Nonetheless, FX-AUDIO offers and recommends to install their custom-tailored Thesycon drivers which can be found on their website.

At this time, the unit does not have any firmware updates available.


SEE ALSO: Coupons – Discounts – Deals – Promo Codes – Sales Deals

Follow us:



Get the latest reviews on your favorite social network


Scores Scores

FX-AUDIO DAC-M1 Scores

FIND ALL OUR: Earphones Reviews / In-Ear Headphones Reviews

MORE: Best Earphones Charts


Buy it from:

SEE ALSO: Coupons – Discounts – Deals – Promo Codes – Sales Deals

Frequency Response (raw)

FX-AUDIO DAC-M1 Frequency Response Curve

curves= modes: USB, Bluetooth, optical

RECOMMENDED FOR YOU: Headphones Frequency Response Curves

SEE ALSO: KZ Headphones Frequency Response Curves


Specifications

FX-AUDIO DAC-M1 Technical Specifications

TypeAmp/DAC
USB DACYes
Max output500 mW
BluetoothYes, 5.0
aptX/LDACYes
ScreenYes
Speaker ampNo
DSD512
Sampling768kHz, 32bit
IR remoteYes
